TIGER BEARING 6207-C-2Z

Tiger Deep Groove Ball Bearing 6207-C-2Z

This FAG 6207-C-2Z deep groove ball bearing is used within the compatible Tiger driveline assembly. Its single-row design supports radial loads together with axial loads in both directions, making it suitable for rotating transmission and driveline components.

Metal shields are fitted on both sides to retain lubricant and help protect the internal raceways from dirt and debris. The Generation C internal design provides low friction and smooth operation, while the steel cage securely guides the rolling elements.

The bearing measures 35 mm internally, 72 mm externally and 17 mm wide. During installation, apply force only through the ring receiving the interference fit to prevent damage to the raceways.

Specifications:

• Manufacturer: FAG
• Application: Tiger driveline assembly
• Bearing Type: Single-row deep groove ball bearing
• Bearing Designation: 6207-C-2Z
• Bore Diameter: 35 mm
• Outside Diameter: 72 mm
• Width: 17 mm
• Closure Type: Metal shields on both sides
• Cage Material: Sheet steel
• Quantity: One
• SKU: TG2501
